| Nguồn gốc: | Thâm Quyến, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | SGS ISO9001:2015 CE ROHS2.0 REACH |
| Số mô hình: | Fmn.2tm.302.js14 |
| Số lượng đặt hàng tối thiểu: | 1 PC |
| Giá bán: | negotiable |
| chi tiết đóng gói: | 50pcs/ctn |
| Thời gian giao hàng: | 2-3 ngày làm việc |
| Điều khoản thanh toán: | L/C, D/A, D/P, T/T, Western Union, Moneygram |
| Khả năng cung cấp: | 50000 chiếc mỗi tuần |
| Người mẫu: | Rm-fmn.2tm.302.js14 | Tên PRCT: | Đầu nối bảng điều khiển |
|---|---|---|---|
| Có sẵn vỏ: | 00b, 0b, 1b, 2b, 3b, 4b, 5b | Liên hệ không: | 2,3,4,5,6, .7,8,9,10,12,14,16,21,26,30,32 |
| Vật liệu cách điện: | PPS, PEEK | ứng dụng: | Năng lượng điện |
| Làm nổi bật: | outdoor electrical connector,waterproof cord connector |
||
RAYMO OEM waterproof power connector for military defence RM-FMN.2TM.302.JS14
FMN.2TM power connector, can be 100% compatible with JONHON connector, Cable connector, panel mount socket
Raymo electronics technology ltd is a professional push pull connector manufacturer intergrating connector researching, designing and development,prction and sales !.
Raymo offer you various range of push pull circular connectors and cable assembly.
You will find raymo connectors in widely range of military denfence, medical, Test and measurement,High Speed Camera,Submarine industry.
| Raymo Part No. | Item Description | |
| RM-FMN.2TM.302.JS14 | circular power connector, 2pin female contact, collet 14, brass with Oxidation treatment in black colour |
| Operating voltage | 300V |
| Current | 35A |
| Voltage resistance | 1000V AC |
| Insulation resistance | ≥2000MΩ |
| Operating temperature | -40°C +110 °C |
| Mating life | 5000cycles |
| Salt spray | 720hrs |
| Waterproof | IP68 |
| Max cable thickness | 6.0mm² |
| Match cable OD | φ11-φ14 |
| RoHS 2.0 | Compliance |
| CE | Compliance |
| Technical Characteristics | |||
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | 720hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 68 | Endurance(shell) | 5000 mating cycles |
