| Nguồn gốc: | Thâm Quyến, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| Số mô hình: | ECG.0B.307.Cln |
| Số lượng đặt hàng tối thiểu: | 1Piece |
| Giá bán: | negotiable |
| chi tiết đóng gói: | 100 cái/thùng |
| Thời gian giao hàng: | 5-8 ngày làm việc |
| Điều khoản thanh toán: | D/A, D/P, T/T, Western Union, MoneyGram, L/C |
| Khả năng cung cấp: | 5000pcs/tuần |
| Tên PRCT: | Đẩy ổ cắm đầu nối tròn kéo | Cấu trúc nâng cao: | tự khóa |
|---|---|---|---|
| Mutiple Pin: | 7 chân | liên hệ: | PCB/in |
| ứng dụng: | Kiểm tra & Đo lường/Thiết bị y tế/Năng lượng/cực đoan | Xếp hạng hiện tại: | 2.5a |
| chỉ số bảo vệ: | IP50 | Giới tính: | Nữ giới |
| Làm nổi bật: | 2.5A 7 Pin Circular Connectors,IP50 7 Pin Circular Connectors,IP50 Male Plug Connector |
||
IP50 2.5A 7 Pin Circular Connectors ECG.0B.307.CLN Panel Mount
ECG.0B.307.CLN Panel Mount PCB Socket Receptacle 7pin Circular Push Pull
1. ECG.0B.307.CLN push pull connector Prct Description:
RAYMO RM-ECG-0B-307-KP can 100% compatible with Lemo original ECG.0B.307.CLN, customer choose our connector as it's high quality, competitive price, fast delivery, and fast respond after-sales service.
RM-B Series offers a mlar, ergonomic, rugged and reliable circular multipole connector for applications needing quick and secure Push-Pull latching. Making it an ideal choice for test and measurement, instrumentation, medical devices, research and audio/video applications.
2. ECG.0B.307.CLN push pull connector techinical characteristics
| Prct attribute | Attribute Value |
| Manufacturer | RAYMO |
| Prct name | Circular push pull connectors |
| Connector type | Panel mount receptacle socket |
| Contact Gender | Pole(Female) |
| Number of contacts | 7 contact |
| Mounting Style | Panel |
| Termination Style | PCB |
| Current Rating | 2.5A |
| IP Rating | IP50 |
| Series | 0B |
| Shell Plating | Chrome |
| Shell Material | Metal |
| Certifications | ISO9001/ CE/ ROHS2.0/ SGS |
| Temperature Range | -55°C, +250°C |
| Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] |
| Salt spray corrosion test | >96hrs |
| Climatical Category | 50/175/21 |
| Humidity | Up to 95% at 60°C |
3. ECG.0B push pull connector metal circular push pull connector with below features:
•Advanced structure: Self-locking
•High pin density contributing to equipment miniaturization
•Shell size 0B
•Contacts from 2-9pins
•Alignment Key and Polarized Keying System to avoid cross-interface
•360° EMC shielding
•Robust and shock resistant designs
4. ECG.0B push pull connector Application
•Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
•Medical equipments like Disposable equipment
•Test & measurement like Data acquisition
•Broadcast, like HD and SD cameras
•Energy, like Renewable energies
•Extreme, such as Sailboat racing
