| Nguồn gốc: | Thâm Quyến, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | SGS, REACH, RoHS2.0, ISO:9001-2015, CE |
| Số mô hình: | Fgg.1kc.304.clad52z |
| Số lượng đặt hàng tối thiểu: | 5 cái/cái |
| Giá bán: | negotiable |
| chi tiết đóng gói: | Túi nhựa & thùng carton |
| Thời gian giao hàng: | 5-7WDS |
| Điều khoản thanh toán: | Liên minh phương Tây, L/C, D/A, D/P, T/T |
| Khả năng cung cấp: | 5000 Miếng/ Tuần |
| Sự miêu tả: | đầu nối kéo nước đẩy | Kích cỡ vỏ: | Kích thước vỏ 1K |
|---|---|---|---|
| Liên lạc: | 2pin 3pin 4pin 5Pins cho đến khi 32pin | Màu vỏ: | Màu đen |
| Bảo hành: | 5000 lần đẩy thời gian | Xếp hạng IP: | IP68, 24 giờ không thấm nước |
| Chấm dứt: | Thiết bị đầu cuối hàn | Chất liệu pin: | Thau |
| Làm nổi bật: | EGG EEG Circular Push Pull Connectors,Black Shell Circular Push Pull Connectors,Waterproof Push Pull Cable Connectors |
||
K Series FGG EGG EEG Black Shell 3 Ways Waterproof Push Pull Circular Connector Red Camera
K series waterproof push pull circular connector wire connector
Model (RM-FGG).Series (0K…3K).Key (G).Contacts. connector straight Plug, collet nut
K series waterproof automotive push pull circular connector with the following main features:
K series circular connectors have been specifically designed for outdoor applications.
They include an inner sleeve and two seals to prevent penetration of solids or liquids into the housing formed by the plug,
free socket, fixed socket or coupler. All models of this series are watertight when mated to give a protection index of IP68.
Prct size:
Note: All our part numbers begin with” RM-”, for example: RM-FGG.0KC.302.JS52Z
“52” is the size of cable collet 5.0MM(request for cable diameter).
K series IP68 IP67 ip66 waterproof push pull circular connector have the same insulators as the B series and have
the following main features:
1. Security of the Push-Pull latching system.
2. Watertight connection (IP 68/IP 66).
3. Multipole types 2 to 32 contacts.
4. Solder, crimp or print (straight or elbow) contacts.
5. Keying system («G» key standard) for connector alignment.
6. Multiple key options to avoid cross mating of similar connectors.
7. 360° screening for full EMC shielding.
8. High packing density for space savings.
9. Rugged housing for extreme working conditions.
Technical characteristics for push pull circular connector :
1. Endurance: > 5000 mating cycles.
2. Humidity : up to 95% at 60 ℃.
3. Temperature range: -40 ℃, +250℃.
4. .Resistance to vibration: 15 g[10 HZ-2000HZ].
5. Shock resistance: 100 g ,6 MS.
6. Salt spray corrosion test : > 48h.
7. Protection index (mated) : IP 68/IP 66.
Industry Application for push pull circular connector :
it is usually widely used on all kinds of outdoor applications, specially for the signal transmission, Medical Equipment ,
Audio / Video, Test and Measurement, Communications prct line.
Raymo, a professional metal and plastic push-pull connector and cable assembly exporter & manufacturer to serve over 39 countries and regions many years, with professional R&D, excellent craftsmanship, high quality & competitive price to meet clients’ real needs, help to cost down and shorten delivery time.
