| Nguồn gốc: | Thâm Quyến, Quảng Đông, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | RoHS, Reach, SGS, ISO:9001-2015 |
| Số mô hình: | PAG.M0.3GL.AC52R |
| Số lượng đặt hàng tối thiểu: | 1 miếng/miếng |
| Giá bán: | negotiable |
| chi tiết đóng gói: | Túi & Thùng PE |
| Thời gian giao hàng: | 3-5 ngày làm việc |
| Điều khoản thanh toán: | Western Union, T/T, Moneygram, D/P, D/A, Moneygram, L/C |
| Khả năng cung cấp: | 5000 Miếng/ Tuần |
| Kiểu: | Đầu nối kéo nhựa Redel | Liên hệ với No.: | 3pin |
|---|---|---|---|
| Giới tính: | nam giới | người cách điện: | PPS, PEEK |
| Chu kỳ: | 1000 | Vật liệu vỏ: | PC, PSU, Peek |
| Màu vỏ: | Đỏ, xám, xanh lá cây, đen, vàng, trắng, xanh | ứng dụng: | Màn hình thai nhi y tế Edan, Màn hình ECG |
| Làm nổi bật: | Red Plastic Push Pull Connectors,Straight Plug Plastic Push Pull Connectors,ECG Monitor Push Pull Electrical Connectors |
||
Raymo Pag Paa Pac Red Plastic Push Pull Connector Straight Plug
P Series plastic push pull connector with the following main features:
1) Small size to accommodate cable diameter up to 6.5 mm and allow up to 14 solder contacts.
2) Lightweight and rugged materials,rapid push-pull locking system.
3) Out shell-POLYCARBONATE (PC),Insulator-PPS,RoHS certified can be sterilized by gas or by steam.
4) The contacts are gold-plated over copper and nickel.
5) Straight and Elbow;PCB and Solder contacts.
6) At least 1000 mating/unmating cycles without significantly affecting the electrical characteristics.
7) A keying system combined with colour coding can be prevention of mismating.
Industry Application of plastic push pull connector:
It has 2,3,4,5,6,7,8,9,10,14 pins for your choice,which can be widely used in medical ECG equipment,detection system,test system,instrumentation,endoscopy,computer system,electronic/mixed coaxial unlimited equipment and so on.
1P series connectors manufactured by RAYMO are lightweight circular medical connectors designed to transmit signal, power, liquids, and gasses in a wide variety of medical, industrial, and test and measurement equipment. They are 75% lighter weight and 200% cost than comparable metal connectors, reliable push-pull locking mechanism, highly resistant to chemicals, and apply to autoclave and other sterilization processes, enable simply plug in and space saving, we can offer IP50 and IP64 protection when mated.
The size is M14 with up to 14 positions, solder or PCB contacts, RAYMO also can offer connectors cable assemblies and over molded cable
Prct size of plastic push pull connector :
Note:All our part numbers begin with” RM-”, for example: RM-PAG-1PC-303-JS52GR
“52” mean the size of cable collet 5.2MM (request for cable diameter).
Color options: G (Grey),N (Black),A (Blue),J (Yellow),R (Red),V (Green), B (White)
RAYMO has designed,manufactured and distributed circular plastic Push-Pull connectors;they are especially adapted for applications such as medical electronics and test & measurement.We offer a wide choice of connectors with various contact configurations,multipole contacts and fluidic connectors.In addition,a range of one time use connectors and connectors for mains power is available.The plastic connectors are available in two sizes,depending on the cable diameter.solutions.
RAYMO as an OEM/ODM manufacturer which can offer medical push-pull connect the system with low voltage contacts solutions.
The 1P series low-voltage contacts female connectors are available with complete cable assembly as a system solution. We use cables customized to market requirements for industrial and medical applications – tailor-made for the respective requirements! This service enables us to offer our customers the RAYMO 1P series low-voltage connectors and cables for meet their applications, including full cable assembly, as a standard solution for the medical and industrial markets
