| Nguồn gốc: | Quảng Đông, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | CE / RoHS / SGS / ISO9001:2015 |
| Số mô hình: | Raymo rm-fpg.1k.302.Clac72z |
| Số lượng đặt hàng tối thiểu: | 1 PC |
| Giá bán: | USD16.98/PC |
| chi tiết đóng gói: | Túi & Thùng PE |
| Thời gian giao hàng: | 5-8 ngày làm việc |
| Điều khoản thanh toán: | T/t |
| Khả năng cung cấp: | 5000pc mỗi tuần |
| Phong cách kết nối: | Đầu nối kéo chống thấm nước tròn | Loạt: | 1k |
|---|---|---|---|
| Liên hệ với No.: | 2pin, 2 cách | Chìa khóa: | 1 khóa (g, 0 độ) |
| Xếp hạng IP: | IP68 | Vật liệu nhà ở: | Mạ crôm tự nhiên |
| Mô hình vỏ: | phích cắm góc phải | Liên hệ có sẵn: | 3way, 4way, 5way, 6way, 7way, 8way, 9way, 10way, 14way, 16way |
| Làm nổi bật: | FPG Electrical Push Pin Connectors,IP68 Electrical Push Pin Connectors,FPG Push Pin Wire Connectors |
||
Watertight Vacuum FPG Electrical Push Pin Connectors Right Angle Plug
Watertight Vacuum FPG Electrical Push Pin Connectors Right Angle Plug
RAYMO Circular Waterproof Push Pull Connector Application
RAYMO's high quality circular waterproof push pull connectors are found in a variety of challenging applications and environmetns including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
P/N: RAYMO RM-FPG.1K.302.CLAC72Z Natural Chrome Plated Right angle Plug Circular Waterproof Push Pull Connector
Description: 0K series right angle cable mount plug, waterproof push pull connector, 2pin male contact,7.2mm cable collet for OD6.2-7.2mm cable, brass shell with neutral chrome plated, 1 key, 0 degree, nut for a black rubber bend relief,
|
Shell size |
Contacts No. with solder & PCB type |
|
0K |
2 3 4 5 6 7 9pin |
|
1K |
2 3 4 5 6 7 8 10 12 14 16pin |
|
2K |
2 3 4 5 6 7 8 10 12 14 16 19 26pin |
|
3K |
3 4 6 7 8 10 12 14 16 18 21 30 32pin |
Circular Watertight Vacuum Push Pull Connector Main features:
– Security of the Circular Push Pull Connector
– Watertight connection (IP 68/IP 66)
– Multipole types 2 to 32 contacts
– Solder or print (straight or elbow) contacts
– Keying system («G» key standard) for connector alignment
– Multiple key options to avoid cross mating of similar connectors
– 360° screening for full EMC shielding
– High packing density for space savings
– Rugged housing for extreme working conditions.
– High quality with reasonable prices
|
Technical Characteristics Raymo Circular Push Pull Connector |
|||
|
Endurance |
>5000 cycles |
Salt spray corrosion test |
>96h |
|
Humidity |
Up to 95% at 60℃ |
Protection Index (mated) |
IP68 |
|
Temperature Range |
-55°C~250°C |
Climatical category |
55/175/21 |
|
Resistance to Vibration |
10-2000Hz,15g |
Shielding |
>95db at 10MHZ >80db at 1GHZ |
|
Shock Resistance |
>100g, 6ms |
Certification |
CE, RoHS, SGS |
Circular Waterproof Push Pull Connector Photo & Dimensions:
Our Service
1. High Quality: CNC machine, professional engineer, skilful worker, responsible QC ensure our high quality prcts;
2. OEM & ODM: OEM & ODM services are welcome;
3. Sample policy: Free sample & sample order are accepted;
4. Fast delivery: 3~5 working days after receiving payment for normal connectors;
5. Fast Respond: within 24 hours for your inquiry and any other questions;
6. After-sale Service: Follow up your shipment. Provide professional solutions for your questions.
Raymo Circular WaterproofPush Pull Connector Overseas Exhibitions
2014/04/11-15 HK Fair
2014/10/11-15 HK Fair
2015/10/2-7 ICEEB, Brazil
2016/04/1115 HK Fair
2017/09/11-16 NAB Show, Netherlands
2018/11/13-16 Electronica 2018, Munich, Germany
FAQ About Raymo Circular Waterproof Push Pull Connector
1. Are your company a professional circular push pull connector manufacturer?
Raymo: Yes, we specialized in prcing Circular Waterproof Connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T prepayment when customer place order .
6. Does your prct have any warranty?
Raymo: Yes, all of our push pull connectors can work normally after 5000 cycles mating; our factory has instruments to test before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
