| Nguồn gốc: | Quảng Đông, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Số mô hình: | RM-DBP-AF1C-A15-KS |
| Số lượng đặt hàng tối thiểu: | 1 |
| Giá bán: | $7.47-8.28 |
| Kiểu: | Din | Giới tính: | Nữ giới |
|---|---|---|---|
| Kích cỡ vỏ: | AF/1031 | Liên hệ với No.: | 15pin |
| người cách điện: | PPS/PEEK | Loại liên hệ: | Liên hệ hàn nữ |
| Xếp hạng IP: | IP68 | Sức chịu đựng: | 5000 chu kỳ giao phối |
| Độ ẩm: | lên đến 95% ở 60 ° C/140F | Phạm vi nhiệt độ: | -65 ° C, +200 ° C |
| Khả năng chống rung: | 15 g [10 Hz - 2000 Hz] | Sốc kháng: | 100 g [6 ms] |
| Thử nghiệm phun muối: | > 96 giờ | Thể loại khí hậu: | 50/175/21 |
| Che chắn: | > 75 dB [ở 10 MHz],> 40 dB [ở 1 GHz] | ||
| Làm nổi bật: | DIN female circular connector 15 pins,IP68 waterproof push pull connector,AF1031 circular push pull connector |
||
| Attribute | Value |
|---|---|
| Type | DIN |
| Application | Audio & Video |
| Gender | Female |
| Connector Type | Circular Push Pull connector |
| Shell size | AF/1031 |
| Contact No. | 15pins |
| Insulator | PPS/PEEK |
| Contact type | Female solder contacts |
| IP Rating | IP68 |
| Warranty | 5000 Times Push Pull |
| MOQ | 1PC |
| Endurance(shell) | 5000 mating cycles | Humidity | up to 95% at 60° C/140F |
| Temperature Range | -65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [6 ms] | Salt spray corrosion test | >96 hr |
| Climatical Category | 50/175/21 | Shielding (min) | >75 dB [at 10 MHz], >40 dB [at 1 GHz] |
Raymo connector is a professional supplier of high-end connector solutions, with advanced production equipment, testing equipment, high-end CNC lathe and a professional team. We are dedicated to providing innovative solutions and high quality products for industrial, telecommunication, military, medical and automotive markets.
By the end of 2019, the company has successfully passed the ISO9001 (2015) quality system certification, ROHS certification, CE certification, Reach certification and other authoritative certifications.
Loading Port: Shenzhen, China
Goods can be shipped by air shipping, sea and other methods. Delivery time depends on order quantity and exact items.
