| Nguồn gốc: | Quảng Đông, Trung Quốc |
|---|---|
| Hàng hiệu: | RAYMO |
| Chứng nhận: | CE ROHS2.0 REACH ISO:9001-2015 |
| Số mô hình: | RM-S-AF1S-P19JS-052/DBPU-AF1S-P19KS |
| Số lượng đặt hàng tối thiểu: | >=1 Cái |
| Giá bán: | negotiable |
| chi tiết đóng gói: | Túi nhựa và thùng |
| Khả năng cung cấp: | 5000 miếng/miếng mỗi tuần |
| Kiểu: | phích cắm chống nước | ứng dụng: | Âm thanh & video |
|---|---|---|---|
| Giới tính: | Nam và nữ | Giấy chứng nhận: | ISO9001/CE/ROHS/SGS |
| Xếp hạng IP: | IP68 | phong cách /mô hình vỏ: | Cắm thẳng và ổ cắm cố định |
| Vật liệu nhà ở: | Đồng thau mạ đen /tự nhiên | liên hệ không: | 10,12,15,19pin |
| người cách điện: | PPS | Loại liên hệ: | Loại hàn |
| Cáp hoặc không có: | Đúng | Tối đa. giao phối: | 5000 |
| MOQ: | Không giới hạn MOQ | Cổng: | Thâm Quyến |
| Làm nổi bật: | waterproof wire connectors,waterproof cable connector |
||
|
Technical Characteristics
|
|||
|
Endurance(shell)
|
5000 mating cycles
|
Humidity
|
up to 95% at 60° C/140F
|
|
Temperature Range
|
- 65° C, +200° C
|
Resistance to vibrations
|
15 g [10 Hz - 2000 Hz]
|
|
Shock Resistance
|
100 g [ 6 ms]
|
Salt spray corrosion test
|
>96 hr
|
|
Climatical Category
|
50/175/21
|
Shielding (min)
|
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
|
|
IP Rating
|
IP 68
|
Certifications
|
ISO9001/CE/ROSH/SGS
|
|
RM-S-AF1S-P19JS-052/RM-DBPU-AF1S-P19KS
|
|||
|
Shell model
|
S straight plug / DBPU socket
|
Shell size
|
1031 series/ AF
|
|
Gender
|
Male and female
|
Contact No.
|
10,12,15,19
|
|
MOQ
|
no limit
|
Delivery
|
3-5 working days
|
1. Security of the push-pull self-latching system;
2. Multipole types with 2 to 19 pins contacts;
3. Solder or PCB contacts(straight or elbow);
4. 360°screening for full EMC shielding;
5. High-density installation for space-saving ;
6. Multiple key options to avoid cross mating of similar connectors;
7. Made of bronze beryllium and have a gold-plated surface;
8. Have brass out shells which have a chrome nickel-plated surface.
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
Raymo Connectors Co., Ltd. is located in Shenzhen China. We are a professional manufacturer of connectors and cable assembly. And we are seting design, development, manufacturing as a professional manufacturer.We focus on a series of fashion accessories, a wide range of diversity, reasonable price and on-time delivery.
1. Main prcts: connectors and cable assembly
2. High quality, competitive price, fast delivery ( 5-7 working days)
3. Main market: North America, Europe, Asia, North Africa, Oceania
4. OEM Manufacturing welcome: Prct, Package...
5. No MOQ limited
6. Free sample available.
7. We will reply you for your inquiry in 24 hours.
8. after sending, we will track the prcts for you once every two days, until you get the prcts. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 5 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 1-2 working days, mass prction for 5-10 working days.
5.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
